DIRECT LIQUID HEATING
Immersion Flanged Tubular Water Heaters
Immersion Flanged Tubular Water Heaters by LICHENGDA. Wetted material and minimum liquid level, configuration details and made-to-drawing quotation for tanks and process vessels.
Product image gallery (6)
PRODUCT ENGINEERING
Wetted material and minimum liquid level
Immersion Flanged Tubular Water Heaters: Select the sheath against the actual liquid chemistry, concentration and operating temperature. Confirm insertion length and thread or flange geometry from the tank drawing.
Keep the active section submerged during operation. Review liquid-level and independent temperature protection, sediment buildup and access for scale removal before commissioning.
For Immersion Flanged Tubular Water Heaters, request the missing voltage, power and finished dimensions before calculating current, selecting a supply or fixing the mounting pattern.
The archived configuration for Immersion Flanged Tubular Water Heaters lists Power: Depends on the dimension; Power tolerance: 5%-10%. Treat these as reference options and reconcile them with the named configuration and installation drawing before quotation.
For Immersion Flanged Tubular Water Heaters, send the supply, continuous and peak temperature, mounting drawing, lead exit and quantity. Include the heated medium and control method so the quoted configuration can be checked against the actual duty.
Application and reference configuration
Tanks and process vessels. The final suitability of Immersion Flanged Tubular Water Heaters depends on the assembled equipment and agreed operating conditions.
Archived figures below describe reference options or a product series. Confirm the exact model specification in the quotation.
| Heat intensity | Not exceeding 30w/cm² |
|---|---|
| Power | Depends on the dimension |
| Insulation | 5 Min ohmios 500w min |
| Power tolerance | 5%-10% |
| Working temperature | 800 ℃ max |
| Warranty | 1 year |
ARCHIVED PRODUCT INFORMATION
Description
flange immersion heater is a type of immersion heater that is designed with a flanged connection for easy installation and removal in various industrial and commercial applications. It consists of a heating element housed within a metal sheath, and the flanged connection allows it to be mounted onto the walls of tanks, vessels, or pipes, with the heating element immersed directly in the liquid to be heated.
|
Heat intensity |
Not exceeding 30w/cm² |
|
Power |
Depends on the dimension |
|
Insulation |
5 Min ohmios 500w min |
|
Power tolerance |
5%-10% |
|
Working temperature |
800 ℃ max |
|
Warranty |
1 year |
Uniform heating, high thermal efficiency, rapid heating, rapid heat conduction, seamless steel pipe, corrosion and rust resistance.
Here are some key features and applications of flange immersion heaters:
Features:
Flanged Connection: The flange is a flat, circular disk with holes for bolts, making it easy to attach and secure the immersion heater to a container or vessel.
Heating Element: The heating element is usually made of a resistant material such as stainless steel, Incoloy, or other alloys, depending on the intended use and compatibility with the liquid being heated.
Terminal Enclosure: Flange immersion heaters often come with a terminal enclosure that houses the electrical connections and provides protection from moisture and environmental factors.
Thermostat or Temperature Sensor: Many flange immersion heaters are equipped with built-in thermostats or temperature sensors to regulate the liquid temperature and prevent overheating.
Applications:
Industrial Processes: Flange immersion heaters are commonly used in various industrial processes, including heating oils, chemicals, solvents, and other liquids for manufacturing, processing, and material handling.
Water Heating: They are used for heating large quantities of water in industrial boilers, water storage tanks, and heating systems.
Food and Beverage Industry: Flange immersion heaters can be employed to heat liquids in food and beverage production, such as cooking oil, chocolate, syrup, and industrial cooking vats.
Chemical Reactions: These heaters are utilized in chemical reactions and laboratory settings where precise and controlled heating is required.
Oil Industry: Flange immersion heaters are often used for heating oil in storage tanks and equipment in the oil and gas industry.
Plating and Galvanizing: They are used in metal plating and galvanizing processes, where precise temperature control is crucial for achieving desired results.
Pharmaceuticals: Flange immersion heaters are utilized for heating liquids in pharmaceutical manufacturing processes.
Water Treatment: In water treatment facilities, these heaters can be used for heating chemicals or water in various treatment processes.
Flange immersion heaters offer versatility and flexibility due to their easy installation and compatibility with a wide range of liquids and environments. Proper sizing, material selection, and control mechanisms are important considerations to ensure safe and efficient operation in specific applications.
Company Information
Xiamen Lichengda Precision Manufacturing Co., Ltd. was founded in 2003, it has a registered capital of 10 million and 100 employees. The plant covers an area of 2000 m² and owns 20+ advanced production equipment imported from home and abroad.
Main products: industrial heater elements and temperature measuring instrument.
Documentation: confirm the CE, RoHS, quality-system and test documents applicable to the quoted product and order.
Enterprise philosophy: Customer and Quality First, Product quality is the vitality of an enterprise.
