Electric Pi Heating Elements
Electric Pi Heating Elements by LICHENGDA. Surface contact and flexible circuit layout, configuration details and made-to-drawing quotation for surface warming and compact equipment assemblies.
Product image gallery (5)
PRODUCT ENGINEERING
Surface contact and flexible circuit layout
Electric Pi Heating Elements: Define the heated outline, substrate material and mounting method. Continuous contact supports uniform heat transfer; air pockets, folds or partial bonding can produce local hot spots.
Keep the active circuit clear of fasteners and sharp bends. Confirm adhesive compatibility, lead strain relief and sensor location at the substrate rather than selecting power from pad area alone.
For Electric Pi Heating Elements, request the missing voltage, power and finished dimensions before calculating current, selecting a supply or fixing the mounting pattern.
The archived configuration for Electric Pi Heating Elements lists Power density range: 0.03w/cm2~2.5w/cm2 / (0.19w/inch2~16.13w/inch2); Voltage: 3.7v-220v; Material: polyimide; Power: 1-6.5w/cm2. Treat these as reference options and reconcile them with the named configuration and installation drawing before quotation.
For Electric Pi Heating Elements, send the supply, continuous and peak temperature, mounting drawing, lead exit and quantity. Include the heated medium and control method so the quoted configuration can be checked against the actual duty.
Application and reference configuration
Surface warming and compact equipment assemblies. The final suitability of Electric Pi Heating Elements depends on the assembled equipment and agreed operating conditions.
Archived figures below describe reference options or a product series. Confirm the exact model specification in the quotation.
| Power density range | 0.03w/cm2~2.5w/cm2 / (0.19w/inch2~16.13w/inch2) |
|---|---|
| Thickness | 0.15-0.18mm |
| thermocouple | K or J type |
| Voltage | 3.7v-220v |
| Wattage | 3w-100kw |
| Material | polyimide |
| Resistance Precision | ±10%ak±0.5Ω |
| Power | 1-6.5w/cm2 |
ARCHIVED PRODUCT INFORMATION
Description
Polyimide heater (Kapton heater) is available in a variety of shapes, sizes, and wattages, it is a clear amber colored polyimide film. The process for making flexible heating film is similar to that of Etched Foil Silicone heaters.It is a high-temperature flexible heating element with excellent dielectric properties capable of operating environments between -60 degree celsius to 250 degree Celsius.
|
Power density range |
0.03w/cm2~2.5w/cm2 / (0.19w/inch2~16.13w/inch2) |
|
Thickness |
0.15-0.18mm |
|
thermocouple |
K or J type |
|
Voltage |
3.7v-220v |
|
Wattage |
3w-100kw |
|
Material |
polyimide |
|
Resistance Precision |
±10%ak±0.5Ω |
|
Power |
1-6.5w/cm2 |
The thickness is about 0.3mm, the lead wire is 150mm. backing adhesive by default.
The pi film is a high-temperature electric heating film, and the surface temperature of theproduced product is
less than 200 oC;PET is a low-temperature electric heating film, and the surface temperature of the productproduced is ≤ 100 0C
Welding front protruding through insulation with red adhesive dotsThe front of the riveted joint protrudes
outward and is insulated with insulating tape
With temperature measuring wires: thermistors, K-type thermocouples, PT100
1: Light and soft texture, good bending, shape can be customized with equipment, excellent anti-aging performance
2: Surface heating, with uniform heating performance and faster heating rate
3: Non layered and non oxidizing, with a service life 10 times that of traditional electric heating elements.Adopting advanced technology and strict quality inspection, it can be added with adhesive backing
Technical Parameter
1:Heating core: Alloy 2:Thickness: ≤0.3mm 3:Voltage: 3.7-220V
4:Operating temperature:≤150 ℃ 5:Power: Designed according to environment
6:Power deviation: ± 5℃ 7:Tensile strength of lead:>5N
Polyimide heaters are known for their flexibility, durability, and resistance to high temperatures and harsh
environments. They are typically used in applications where a thin and flexible heating element is required
such as in medical equipment, aerospace applications, and electronics.
One of the advantages of polyimide heaters is their ability to conform to irregular surfaces, which makes
them ideal for use in equipment that has complex geometries or tight spaces. They can also be easily
customized to fit specific shapes and sizes, which allows for a high degree of design flexibility.
Polyimide heaters are available in a range of power ratings, from a few watts to several kilowatts, and can
be designed to operate at different voltages and frequencies. They can also be equipped with
temperature sensors and other control devices to ensure precise temperature control and protection
against overheating.
Overall, polyimide heaters are a reliable and cost-effective solution for a wide range of heating applications
offering excellent thermal stability, resistance to moisture and chemicals, and long service life.
Company Profilm
Xiamen Lichengda Precision Manufacturing Co., Ltd. was established in 2 0 1 2 year. It is a
comprehensive company integrating production, sales and technical service. the factory covers an
area of 5000m2, has nearly 100 employees. Applicable quality-system and product-compliance documentation must be confirmed for the quoted product, legal entity and current scope.
Main products : cartridge heater,Tubular heater, Flexible heater, cartridge heater,silicone heater
thermocouple, heating element, and other heating products. The factory introduced advanced
automatic control system and online quality,inspection system to ensure the stability and reliability
of product quality
1. Qucik Response:Your inquiry will be replied within 24 hours. Response Rate over 90%
2. Smooth Communication: Well-trained and experienced staffs to answer all your inquires.
3. Sincere Service Attitude: Treat Customers As Friends. No Questions are Neglected.
4. OEM Accepted: Free Sample,We can customize your products to meet all your different requests.
5. Small MOQ: Small Amount wholesales are supported to meet your needs as well as large demands.
6. Fast Delivery: We have Reliable Forwarders with long term cooperation and Competitive Price.
You may contact any one of our sales and services team: email to us as inquiry.
