6 X 20mm Cartridge Heater 12v
6 X 20mm Cartridge Heater 12v by LICHENGDA. Bore fit and conductive heat transfer, configuration details and made-to-drawing quotation for molds, dies and conductive tooling.
Product image gallery (7)
PRODUCT ENGINEERING
Bore fit and conductive heat transfer
6 X 20mm Cartridge Heater 12v: Install the active sheath in a close-fitting, clean bore. Specify bore diameter, tolerance and heated length together; excessive clearance increases sheath temperature and slows heat transfer.
Record the lead exit, cold end and removal access before the tool is machined. Locate the control sensor near the heated zone without placing it directly against the resistance element.
For 6 X 20mm Cartridge Heater 12v, use the listed 20mm, 12v as catalog identifiers and confirm the complete electrical and dimensional combination before calculating current, selecting a supply or fixing the mounting pattern.
The archived configuration for 6 X 20mm Cartridge Heater 12v lists Resistance heating wire: NiCr 80/20 wire; size: 6*20mm or customized; wire length: 250mm; Length tolerance: ±1 mm. Treat these as reference options and reconcile them with the named configuration and installation drawing before quotation.
For 6 X 20mm Cartridge Heater 12v, send the supply, continuous and peak temperature, mounting drawing, lead exit and quantity. Include the heated medium and control method so the quoted configuration can be checked against the actual duty.
| Catalog name values | 20mm · 12v |
|---|
Application and reference configuration
Molds, dies and conductive tooling. The final suitability of 6 X 20mm Cartridge Heater 12v depends on the assembled equipment and agreed operating conditions.
Archived figures below describe reference options or a product series. Confirm the exact model specification in the quotation.
| Resistance heating wire | NiCr 80/20 wire |
|---|---|
| size | 6*20mm or customized |
| wire length | 250mm |
| Wattage Tolerance | +5%, -10% |
| Resistance tolerance | +10%, -5% |
| Length tolerance | ±1 mm |
| Diameter tolerance | -0.02mm |
| Standard Cold Zone | 5-10mm |
| Insulation resistance (cold) | ≥ 500 MΩ |
| Thermocouple Location | type J / k / ground wire |
